As a projector, the Epson USA Pro L1060W combines LCD technology with a resolution of WXGA 1280 x 800, and is additionally specified with 6000 ANSI lumens and a contrast of 2500000:1. Using this laser phosphor technology, the light source runtime is rated at 20000 hours – calculating to 13.7 years at four hours of use per day. Thanks to the combination of optical lens shift and digital keystone correction, the projected image's position can be adjusted very flexibly. The specifications identify the device as a model with an interchangeable lens option. Matching optional optics allow for exact adaptation to the required image size and projection distance, which can be calculated directly with the Projection Calculator. Looking at practical performance, up to 787 cm can be illuminated with 6000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 525 cm. Regarding signal processing, the model is compatible with incoming 1080P content and 4K. Furthermore, the model supports 360° projections for highly flexible deployment scenarios. Regarding professional networking, the device offers a classic RJ45 LAN port for control alongside HDBaseT for the lossless transmission of picture and sound over long distances. This model dates back to 2020 and is no longer part of Epson USA's current product range. However, it remains one of the frequently accessed models in our database.
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Very large screen width and rooms with plenty of light and shaded daylight.
Light Source
Laser
Light Life
20000 h. 30000 h. in Eco Mode
Operating Costs
0,00 € Laser
Calculated brightness quality The screen width may also be larger. Perfect
288 - 466 cm
Lux:
2400 Lux
Contrast:
2500000:1
Candela pro m²:
764 cd/m²
Foot-Lamberts:
223 fL
84 cm
•
Focus
Powered
Zoom
Powered 1,6
Objective
Throw Ratio
optional
Audio
1 x 10W
Connections
HDMI HDCP 2.2 in
DVI-D in
D-sub 15pin in und out
5 x BNC RGBHV in
Mini Jack Audio in und out
USB in
RS232C Din 9 pin in
RJ45 in
HDBaseT in
Full HD 1080P compatible
