| Customer review |
|
 |
|
| Display Type |
3 x 0,61" SXRD Panel
HDTV 16/9 Silicon X-tal Reflective Display (SXRD)
|
| Ansi-Lumen |
Projector |
- |
Screen |
Lux (200 cm Screen width) |
| Contrast |
- |
-
|
| Black Level |
- |
- |
| Lens shift |
Vert.: +65% -0% Hori.: +/-25%
|
+
Projector
|
| Resolution |
HDTV 1920 x 1080
2.073.600 Pixel |
| Video Modes |
PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p |
| Application |
Stationary | Permanent installation in the training room and meeting room as well as the conference room.
Very narrow picture width and rooms with very little light. |
| Light Source |
200W UHP Lamp
Article Nr.: LMP-H201
|
|
| Light Life |
3000 h. |
| Operating Costs |
-
|
|
| Focus |
Powered |
| Zoom |
Powered 1,6 |
| Objective |
F=2,50-3,40 f=18,5-29,6 mm |
| Throw Ratio |
1,37-2,19:1 show |
| Audio |
Nein |
| Connections |
DVI-D mit HDCP in
RJ45
RS232C Din 9 pin in |
| Ceiling Mounting |
Yes, is possible. |
| Power |
320W |
| Size WxHxD |
470 x 179,20 x 482,40 mm (18,5"x7,1"x19") 40,55 L/dm³
|
| Operating Noise |
- |
Shift: 73 cm
|
Shift: 50 cm
|
|
Shift: 50 cm
|
| |
|
|
| Weight |
- |
| Keystone |
- |
| Illumination |
- |
| Frequenz |
- |
| Foot-Lamberts |
- |
| Candela m² |
- |
| Features |
 Full HD 1080P compatible
Lens shift Funktion
Lan network compatible.
|
|
- |
In Comparison
The Sony VPL GH10 compared to others not current "Stationary" projectors. |
| Ansi-Lumen: |
|
0 |
Weight: |
|
0 |
| Contrast: |
|
0 |
dB: |
|
0 |
| Black level: |
|
0 |
Power cons.: |
|
97 |
| Picture Total Points: | 0 |
Projector Total Points: | 0 |
|
| Popularity Top 100 |
|
| Points: |
|
2 |
| Ranking: |
1532 (From: 2536) |
|
|
|
|
|
| Status |
2008 Discontinued (EOL) // Last update of the data: 2025-02-26
|
