Designed for the Stationary sector, the PT DW750 model from Panasonic features 7000 ANSI lumens, a native WXGA 1280 x 800 resolution and a contrast ratio of 3000:1. The runtime of the lamp in this model is estimated at 4000 hours before a replacement is necessary – mathematically sufficient for 5.5 years based on two hours of use per day. Thanks to the combination of optical lens shift and digital keystone correction, the projected image's position can be adjusted very flexibly. The Lens Shift Calculator helps find the optimal installation dimensions. Looking at practical performance, up to 850 cm can be illuminated with 7000 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 567 cm. Should very large projection surfaces be required, the integrated edge-blending software offers the possibility to seamlessly combine images from multiple projectors without visible seams. For media input, video signals up to 1080P are supported. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. Regarding noise emissions, the model proves to be exceptionally quiet during operation, producing just 30 decibels. The projector was released in 2015 and is officially no longer distributed by Panasonic.
Display Type
1 x 0,65" DLP Chip WXGA 16/10 Ti Digital Light Processing Chip
Stationary | Permanent installation in the training room and meeting room as well as the conference room. Very large screen width and rooms with plenty of light and shaded daylight.
HDMI in
DVI-D
D-Sub 15 pin in
5 x BNC RGBHV in
Video BNC in
S-Video in
RS232C Din 9 pin in und out
Mini jack Remote in und out
RJ458 in
SDI über BNC in
Ceiling Mounting
Yes, is possible.
Power
-
Size WxHxD
498 x 175 x 521 mm (19,6"x6,9"x20,5") 45,41 L/dm³
Operating Noise
30 / 28 dB in Eco Mode
Key: 302 cm Shift: 75 cm
Key: 96 cm Shift: 60 cm
Key: 96 cm Shift: 20 cm
Key: 302 cm Shift: 20 cm
Weight
17,60 kg / 38,8 lbs.
Keystone
Vert.: +/-40° Hori.: +/-15°
Illumination
90%
Frequenz
H-sync: 15-100 kHz V-sync: 24-120 Hz Range max.: 162 MHz
Full HD 1080P compatible
