Proxima DP5155
Proxima Desktop Projektor 5155
Image Proxima DP5155
Customer review
✎ Help other users and be the first to share your review.
✎ Help other and be the first to share your review.
Offer Ads
Discover other popular projectors on Amazon!
Model Overview As a projector for the Standard-Portabel sector, the Proxima DP5155 is equipped with 2200 ANSI lumens, a SVGA 800 x 600 resolution and a contrast of 450:1. The manufacturer specifies a runtime of 3000 hours for this projector's lamp.
A look at the light output reveals: The 2200 ANSI lumens are sufficient to illuminate an image width of up to 408 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 272 cm.
This is a discontinued model that is no longer officially distributed by Proxima.
Display Type       3 x 0,9" LCD TFT Panel
      SVGA 4/3 Liquid Crystal Display
Ansi-Lumen
Projector
 2200
Screen
 733 Lux (200 cm Screen width)
Contrast 450:1 full on/off 450:1 full on/off
Black Level 4,8889 min. Lumen 1,64 min. Lumen
Offset -
Resolution SVGA 800 x 600
480.000 Pixel
SXGA 1280 x 1024 compressed
Video Modes PAL, SECAM, NTSC
Application Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with little light, max. 100 lumens.
Light Source 200W UHP Lamp
Article Nr.: LAMP-031, 22000009
Light Life 3000 h.
Operating Costs -
Calculated brightness quality Perfect
394 - 514 cm
Lux: 733 Lux
Contrast: 450:1
Candela pro m²: 233 cd/m²
Foot-Lamberts: 68 fL

Screen width:cm
          Room:
•
Focus Manual
Zoom Manual 1,3
Objective F=1,8-2,1 f=36-47 mm
Throw Ratio 1,97-2,57:1 show
Audio 2 x 1W
Connections DVI-D
2 x D-sub 15pin in 1 x out
Cinch Video in
Cinch Stereo in und out
S-Video in
Mini Jack
Maus Port
Ceiling Mounting Yes, is possible.
Power 220W
Size WxHxD 248 x 98 x 320 mm (9,8"x3,9"x12,6") 7,78 L/dm³
Operating Noise 34dB
Key: 69 cm

Without offset

Key: 69 cm
Weight 3,40 kg / 7,5 lbs.
Keystone Vert.: +/-10°
Illumination -
Frequenz H-sync: 15-100 kHz
V-sync: 43-130 Hz
Range max.: 230 MHz
Foot-Lamberts 68 fL / max. 408 cm screen width
Candela m² 233 cd/m²
Features -
Screen Mirroring Optional only Google TV / Fire TV / Apple TV / Roku TV / Xiaomi TV Ads
In Comparison
The Proxima DP5155 compared to others not current "Standard-Portabel" projectors.
Ansi-Lumen:
26 Weight:
84
Contrast:
1 dB:
38
Black level:
82 Power cons.:
98
Picture Total Points:36 Projector Total Points:73
Popularity Top 100
0 popularity points 6 popularity points 4 popularity points 1 popularity points 1 popularity points 4 popularity points
Points:
4
Ranking: 3006 (From: 7737)
Optional accessories
ceiling bracket length: 100-120mmHalterung10047,86 €
Airfilter universaluni3mm18,15 €
Status - Discontinued (EOL) // Last update of the data: 2026-06-09
Data
Product Sheet english HC

Projektor Proxima DP5155
