The hardware properties of the ProjectoWrite8 WX31NXT manufactured by Boxlight include 3100 ANSI lumens, a WXGA 1280 x 800 resolution and a contrast value of 3000:1. The manufacturer specifies a runtime of 3000 hours for this projector's lamp. A look at the light output reveals: The 3100 ANSI lumens are sufficient to illuminate an image width of up to 566 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 377 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. Specifically for the educational or business sector, an interactive whiteboard function is also integrated. Equipped with a microphone jack and built-in speakers (10W), audio signals during presentations can be played back directly without an external audio system. This model dates back to 2013 and is no longer part of Boxlight's current product range. However, it remains frequently searched within our database.
Display Type
1 x 0,65" DLP Chip WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3100 / 2200 im Eco Mode
Screen
1240 Lux (200 cm Screen width)
Contrast
3000:1 full on/off
3000:1 full on/off
Black Level
1,0333 min. Lumen
0,414 min. Lumen
Offset
62,5% 16 cm over screen top edge →
SCREEN
+Projector
Resolution
WXGA 1280 x 800
1.024.000 Pixel UXGA 1600 x 1200 compressed
Whiteboard | Training and company presentations, as well as product presentations. Medium screen width or rooms with a little more ambient light, max. 200 lumens.
Calculated brightness quality The screen width may also be larger. Perfect
70 cm (no Zoom)
Lux:
1240 Lux
Contrast:
3000:1
Candela pro m²:
394 cd/m²
Foot-Lamberts:
115 fL
78 cm
•
Focus
Manual
Zoom
No Zoom
Objective
-
Throw Ratio
0,35:1
Audio
1 x 10W
Connections
HDMI in
2 x D-sub 15pin in 1 x out
Cinch Video in
Cinch Stereo in
S-Video in
Mini Jack Audio in und out
USB in
RS232C Din 9 pin in
RJ45 in
12V Trigger out
Mikrofon in
Full HD 1080P compatible
Boxlight Website
Product Sheet english
